I wrote this a while ago but never got round to posting it. The
dust has since settled but it might be interesting to some
nonetheless.
1) I try to use valgrind on
something that involved OpenSSL.
I can't even remember what. The exercise is significantly hampered by
numerous false positives.
2) I identify OpenSSL's practice of passing uninitialized data to
its RNG as part of the problem. This happens in two places.
(i) When RAND_poll (in
crypto/rand/rand_unix.c) collects entropy from /dev/urandom
(or an EGD) , it reads data into a buffer called tmp_buf. It
might not fill this buffer, but it nonetheless passes the whole
buffer into the RNG. The balance of the buffer is uninitialized and
valgrind warnings result.
I spotted this one, and my fix was to zero
out the buffer before filling it. This may not be entirely
obvious from the patch in the bug report but if you read it in context
then it is plainly harmless.
(ii)When you ask for a random number,
ssleay_rand_bytes adds the output buffer you're going to use
for the answer into its calculation of new random data. I didn't spot
this one. This is where the PURIFY ifdef can be found.
My fix for (i) was perfectly safe. Also, it does not cost you
anything: if you were analyzing the security of OpenSSL you would have
to ignore any contribution to entropy from the uninitialized part of
the buffer; its uninitialized state means the compiler and language
standard don't make any promises, it does not mean its
unpredictable on a given implementation. (Early in a program it is
relatively likely to be all 0s for instance). So this change would not
have removed any security guarantee worth the name.
Since I apparently didn't spot (ii) I didn't make any changes
there, though if I had that would have been safe too for the same
reason.
3) I send
my patch for (i) to Debian. I am after all using a Debian
system.
4) Debian's
OpenSSL maintainer spots (ii) as well but misunderstands (i),
apparently concluding that the problem is not
RAND_poll passing (partially) uninitialized data but in
ssleay_rand_add reading that data at all. In other words,
they've assigned the blame for the valgrind warning to the code that
performs the read, rather than the code that fails to do a write.
5) Kurt then
mails openssl-dev about it, and gets a positive reaction a member
of the development team. openssl-dev is the address the README told
you to use:
Development is coordinated on the openssl-dev mailing list (see
http://www.openssl.org for information on subscribing). If you
would like to submit a patch, send it to openssl-dev@openssl.org with
the string "[PATCH]" in the subject. Please be sure to include a
textual explanation of what your patch does.
6) Kurt
makes his proposed changes and uploads
the new package.
Henceforth anyone who installs this tainted OpenSSL suffers two
problems. Firstly there is no longer adequate diversity of keys
generated with it. Secondly if they make any DSA
signatures, they risk exposing the value of the private key.
(You might want to rethink how much you rely on DSA in the light of
this; requiring a source of cryptographic-strength random numbers for
key generation is fair enough but additionally requiring it for every
signature if you don't want to expose your private key seems a little
on the risky side!)
7) Luciano Bello spots the problem. The bug gets fixed and a DSA is
issued. There's a great deal of informed and uninformed comment
online. A number of people blame me, assuming that the only patch that
appears in the bug report is the faulty one, and not bothering to
check either what it does or what the actual change was. Obviously
this does not make me happy.
(There's a lot of great work done by various people to clean up the
mess, too.)
8) Ben Laurie complains that
vendors are bad for security.
There's some truth in there: people should indeed not try to change
code they don't understand, and coordinating with the people who
maintain it is an obvious way to avoid pitfalls. However, Kurt did
mail the advertized address, and did get a response from a member of
the OpenSSL development team, so even though he screwed up, this safety
net failed dismally too.
Some people have criticized the original motivation for any change
as putting debugging ahead of security. Not only is this not true -
the original change had no impact on security - but it is completely
wrong-headed: in general software that is harder to debug is software
that is harder to secure, and in particular the kind of bugs valgrind
is good at spotting are just the kind that may turn out to be security
holes.
